FP605 Drive Quick Setup Procedure and ON-SITE Videos for Small Frames

FP605 Quick Setup Procedures for Small Frame

The videos are a companion to Yaskawa document TOEPC7106171A. This document is packaged with FP605 drive models FP65U2011 to 2114 and 4005 to 4124.

 Playlist Video Title/Description
FP605 Drive Quick Setup Procedure Playlist (124 Output Amps and Smaller)
How to install, wire, and setup the drive for test operation with a motor using the drive keypad and the instructions packaged with the FP605 drive.


This ON-SITE video playlist is a companion to Quick Setup Procedure document TOEPC7106171A and applies to small-frame FP605 drive models FP65U2011 to 2114 and 4005 to 4124.

Mounting an FP605 Drive
Shows how to mount FP605 drive models FP65U2011 to 2114 and 4005 to 4124 to a panel.
(Video No. VP.FP605.05 )
Wiring an FP605 Drive
Shows how to wire main power and motor leads to FP605 drive models FP65U2011 to 2114 and 4005 to 4124.
(Video No. VP.FP605.06)
Running the Motor in LOCAL Mode to Check Motor Rotation
Shows how to run the motor in LOCAL Mode to check motor rotation.
(Video No. VP.FP605.01)
FP605 How-To Playlist
Additional ON-SITE video playlist that applies to all FP605 drives. These videos demonstrate how to maintain, program, adjust, and use some of the many features of the FP605.
FP605: Viewing Modified Parameters
Shows how to view the Modified Parameters on the FP605 keypad.
(Video No. VP.FP605.02)
FP605: Setting the Date & Time on the Drive
Shows how to set the date and time on the FP605 keypad.
(Video No. VP.FP605.04)
