FP605 Drive Quick Setup Procedure and ON-SITE Videos for Large Frames
FP605 Drive Quick Setup Procedure and ON-SITE Videos for Large Frames
The videos are a companion to Yaskawa documents TOEPC7106171B and TOEPC7106171C These documents are packaged with FP605 drive models FP65U2143 to 2396 and 4156 to 4720.
![]() |
Video Title/Description |
---|---|
FP605 Drive Quick Setup Procedure Playlist (143 Output Amps and Larger) How to install, wire, and setup the drive for test operation with a motor using the drive keypad and the instructions packaged with the FP605 drive. This ON-SITE video playlist is a companion to Quick Setup Procedure document TOEPC7106171B and TOEPC7106171C and applies to larger-frame FP605 drive models FP65U2143 to 2396 and 4156 to 4720. |
Wiring an FP605 Drive Shows how to wire main power and motor leads to FP605 drive models FP65U2143 to 2396 and 4156 to 4720. (Video No. VP.FP605.07) |
Running the Motor in LOCAL Mode to Check Motor Rotation Shows how to run the motor in LOCAL Mode to check motor rotation. (Video No. VP.FP605.01) |
|
FP605 How-To Playlist Additional ON-SITE video playlist that applies to all FP605 drives. These videos demonstrate how to maintain, program, adjust, and use some of the many features of the FP605. |
FP605: Viewing Modified Parameters Shows how to view the Modified Parameters on the FP605 keypad. (Video No. VP.FP605.02) |
FP605: Setting the Date & Time on the Drive Shows how to set the date and time on the FP605 keypad. (Video No. VP.FP605.04) |
