Z1000U Matrix Bypass

7.5 - 350 HP
The Z1000U Bypass package provides a Z1000U Matrix drive in a UL Type 1 or UL Type 3R enclosure with an input circuit breaker and a 2-contactor or optional 3-contactor style bypass to allow motor operation from the drive or across the line.
(UL Type 1 Shown)
